Persons Capacity: 16 (standard US spec)

Maximum Weight Capacity: ~5,290 lbs (2,400 kg)

Swamped Capacity: ~5,200 lbs (2,359 kg)

Standard Fuel Capacity: 425 gallons (1,609 L)

Optional Fuel Capacity: (often same tank — optional slimmer or extended tanks vary by market; typical documented is the 425 gal standard)

Length Overall (LOA): 37′ 6″ (11.40 m)

Beam: 11′ 6″ (3.50 m)

Draft (engines up): 2′ 0″ (0.60 m)

Transom Height: ~30″ (0.76 m)

Deadrise at Transom: 23.5°

Bridge Clearance (no top): ~9′ 0″ (2.74 m) — with top & radar ~10′ 4″ (3.15 m), upper station ~16′ 0″ (4.88 m)

Weight (dry, no engines): ~13,500 lbs (6,123 kg)

Weight (with engines, fuel & water): ~18,715 lbs (8,489 kg)

Minimum Power: ~750 hp (typical triple 250 hp Verado setup)

Maximum Power: ~1,050 hp (e.g., triple 350 hp Mercury Verados)

Maximum Engine Weight: ~2,100 lbs (952 kg)

Fresh Water Capacity: 60 gallons (227 L)

Holding Tank Capacity: ~10 gallons (38 L)

Livewell Volume: ~55 gallons (208 L)
